Appendix A-7
The fixed torque of bolt 1 in the Figure is 6 1N m
Out handle can be normally and efficiently used, no linkage
falling off, the backup door can be opened and closed freely
without any jam nor unlocking.
Handle confirmation
rear door assembly
backup door bottom buckle
backup door lock
backup door out handle
The door can be opened and closed smoothly without any jam nor
unlocking.
Torque wrench
door lock assembly
