Appendix D-17
Serial
No.
Working region and
specification
Torque
N·m
Serial
No.
Working region and specification
Torque
N·m
1
upper arm shaft fixed
bolt M14×1.5-10.9
200 25
engine suspension connecting bolt M10×
1.25-10.9
78±10
2
front shaft of lower arm
connecting bolt M16×
1.5-10.9
270±25 26
transmission suspension connecting bolt M10×
1.25-10.9
78±10
3
rear shaft of lower arm
connecting bolt M18×
1.5-10.9
320±30 27
transmission-engine connecting bolt M10×
1.25-10.9
50±5
4
bottom arm limiting
stopper fixed bolt M10
×1.25-8.8
63±5 28 drive shaft connecting bolt M10×1.25-10.9 78±5
5
upper arm ball pin
pedestal connecting bolt
M10×1.25-10.9
78±10 29
drive shaft bearing fixed bolt M10×1.25-8.8
65±5
6
bottom arm ball pin
pedestal connecting bolt
M12×1.25-10.9
140±10 30 wheel nut M12×1.25 135±15
7
front twisted bar
pedestal connecting bolt
M12×1.25-10.9
140±10 31 steering wheel lock nut M12×1.25-8 30±5
8
upper arm ball channel
fixing nut M16×1.5-10
145±15 32 steering gear-carriage fixing nut M12×1.25-8 90±10
70±10
9
front vibration damper
upper fixing nut M10×
1.25-8
Bush
compressed
by 1/3
33
steering angle drive co-carriage bolt M10×
1.5-9.8
50±5
10
bottom arm ball pin
channel fixing nut M18
×1.5-10
230±20 34
steering system universal-joint lock bolt M8×
1.25-8.8
25±3
11
front vibration damper
bottom connecting bolt
M12×1.25-8.8
90±10 35 steering linkage ball fixing nut M14×1.5-8 120±10
12
rear vibration damper
upper fixing nut M10×
1.25-8
Bush
compressed
by 1/3
36
steering linkage adjustment lock nut M14×
1.5-8
60±5
13
rear vibration damper
bottom fixing nut M14
×1.5-8
170±15 37
front axle front shackle connecting bolt M14×
1.5-10.9
180±20
14
front cross stabilizer rod
-carriage fixed bolt M8
×1.25-8.8
23±3 38
front axle rear shackle connecting bolt M14
×1.5-10.9
180±20
