Great Wall hover - Page 424

Appendix D-18
15
front cross stabilizer rod
-connecting bar bottom
arm bolt M10×1.25-8
63±5 39 brake petrol pipe joint M10×1.25 16
16
long longitudinal tie
connecting bolt M14×
1.5-10.9
200±20 40
safety belt body connecting bolt 7/16″-8.8
40±2
17
short longitudinal tie
front connecting bolt
M14×1.5-10.9
180±15 41 safety belt seat connecting bolt 7/16″-8.8 40±2
18
short longitudinal tie rear
connecting bolt M14×
1.5-10.9
200±20 42 body suspension connecting bolt M10×1.25-9.8 63±5
19
cross tie -carriage
connecting bolt M14×
1.5-10.9
200±20 43 Engine oil pan drain bolt 40±5
20
cross tie -rear axle fixing
nut M14×1.5-8
180±15 44 Transmission/transfer case refueling/drain bolt 30～35
21
rear cross stabilizer rod
-rear axle fixed bolt M8
×1.25-8.8
23±3 45 front drive axle refueling bolt M20×1.5 145±5
22
rear cross stabilizer rod
-connecting bar -carriage
bolt M10×1.25-8
63±5 46 Front drive axle drain bolt Rc1/2 30～35
23
standby tire bracket fixed
bolt 10×1.25-8.8
63±5 47 rear drive axle refueling/drain bolt M20×1.5 145±5
24
standby tire lifter fixed
bolt M8×1.25-8.8
25±3 48 Starter and wheel box connecting bolt 30±3
