Hioki 3153 - Page 122

109
_____________________________________________________________________________________________
______________________________________________________________________________________________
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
10
Insulation-resistance test measurement range
Select whether you want to use a fixed or an automatic range as the insulation-
resistance test measurement range. The fixed ranges are automatically selected
depending on the preset lower-limit value. Auto range switches between ranges
depending on the measured value, but it takes time to display this value, since
it is displayed after the range is switched. (This takes approximately 1.5
seconds.)
Selection
0: Fixed range (initial setting)
1: Auto range
11
Insulation-resistance test termination mode
When performing an insulation-resistance test, set whether you want to conduct
the test for the set test time regardless of the decision, terminate the test when
PASS screening is performed, or terminate the test when FAIL screening is
performed. This mode is effective when the test time is set.
Selection
0: Test for set time
1: Terminate test at PASS screening
2: Terminate test at FAIL screening
12
Setting for screening during ramp-up time
Select whether screening is to be performed during ramp-up time in a DC
withstand-voltage test.
Selection
0: No screening during ramp-up time (Initial setting)
1: Screening during ramp-up time
13
PC interface
Enable this function to select a PC interface to be used.
Selection
0: RS-232C (9600 bps) (initial setting)
1: RS-232C (19200 bps)
2: GP-IB
When GP-IB is selected, set the GP-IB address in the lower
column.
Contents GP-IB address: 0to30(initial setting: 3) ("2: GP-IB"is selected)
14
START protection function
Select whether START is to be invalid during the discharge time upon
completion of each test.
Selection
0: Not set (initial setting)
1:Set
15
TEST-signal output
Select whether the external I/O
TEST
――――――
signal output and
TEST
flashing time are
to be included in the TEST-signal output.
Selection
0:
TEST
signal ON, including while
TEST
――――――
is flashing (Initial setting)
1:
TEST
signal OFF, while
TEST
――――――
is flashing
2:
TEST
signal ON, only while
TEST
――――――
is flashing (excluding ramp-
down time)
