10.1 RS-232C Interface
______________________________________________________________________________________________
Bit 7
Unused
Bit 6
Unused
Bit 5
Unused
Bit 4
Unused
Bit 3
EOM
Test completed
Bit 2
LFAIL
Below lower-limit of comparator
Bit 1
UFAIL
Above upper-limit of comparator
Bit 0
PASS
Within limits of comparator
(2) Event status register 0 (ESR0) bit assignments
