33
_____________________________________________________________________________________________
3.3 "SETTING" State
______________________________________________________________________________________________
Test-voltage value: 2.00 kV
Upper-limit value: 20 mA
Lower-limit value: OFF
Test time: 60.0 s
Ramp-up time: 10 s
Ramp-down time: OFF
Test-voltage type: AC 60 Hz
(8) Setting a test-voltage type
Press the key to move the flashing cursor to the AC or DC.
In this example, change the output voltage range from
AC 50 Hz
to
AC 60 Hz
using / keys.
Pressing the / keys changes the display as follows:
AC 50 Hz
→
AC 60 Hz
→
DC
.
(9) Changing to the READY state
To return to the READY state, press the
STOP
key, which will finalize the
test settings. In the READY state,
READY
lights up.
The new parameters following setting are shown below:
