Chapter 8 Saving/loading Preset Values 129
8.1 Saving Preset Values 129
8.1.1 Procedure for Saving Data 129
8.1.2 Example of Saving 132
8.2 Loading Preset Values 134
8.2.1 Procedure for Loading Data 134
8.2.2 Example of Loading 137
Chapter 9 External Interface 139
9.1 External I/O Terminal 139
9.1.1 Signal Line 140
9.1.2 Example of Input Signal Connection 142
9.1.3 Example of Output Signal Connection 144
9.1.4 Inter-lock Function 146
9.1.5 Selecting a Program Test File 147
9.1.6 Timing Chart of External I/O Terminal 149
9.2 Buzzer 154
Chapter 10 PC Interface 155
10.1 RS-232C Interface 156
10.1.1 Specifications 156
10.1.2 Preparing for Data Transfer 157
10.1.3 RS-232C Command Transfer Methods 159
10.2 Command Table 164
10.3 RS-232C Command Reference
167
10.3.1 Common Command Messages 168
10.3.2 Specific Command Messages 171
10.4 Response Formats 201
10.5 GP-IB Interface
203
10.5.1 Specifications 203
10.5.2 Preparing for Data Transfer 203
10.6 GP-IB Command Transfer Methods 205
10.7 GP-IB Commands
211
10.8 GP-IB Command Reference
212
10.8.1 Command Reference 212
10.8.2 Specific Command Messages 216
Chapter 11 Specifications 219
11.1 Basic Specifications 219
11.1.1 Withstand Voltage test portion 219
11.1.2 Insulation resistance test portion 221
