Honeywell UDC2800 User Manual

204
Step Operation Press Result
4 Select Control
set up group
Setup key Until you see Control set up group.
5 Select PID Sets Function key Enter in the first function prompt of the
Control set up group: PV Source.
Increment key
or Decrement
key
Until you see PID Sets.
Press the Function key again to enter in the
first configuration prompt of PID Sets.
6 Select PID Sets
function
Increment key
or Decrement
key
Until you see the selection 2 Sets Keyboard.
Function key Select the selection PD+Manual Reset.
7 Select Local SP
Source
Increment key
or Decrement
key
Until you see Local SP Source.
Function key Enter in the first configuration prompt of
Local SP Source.
8 Select Local SP
Source Function
Increment key
or Decrement
key
Until you see the selection 2 Local SPs.
Function key Select the selection 2 Local SPs.
9 Select SP
Tracking
Increment key
or Decrement
key
Until you see SP Tracking
Function key Enter in the first configuration prompt of SP
Tracking.
10 Select SP
Tracking
function
Increment key
or Decrement
key
Until you see the selection None
Function key Select the selection None.
11 Select Tuning
set up group
Setup key Until you see Tuning set up group.
12 Select Manual
Reset Value
Function key Enter in the first function prompt of the
Tuning set up group.
Chapter 5 - Monitoring and Operating the Controller

Honeywell UDC2800 Specifications

General

Control Modes	PID, ON/OFF, Manual
Mounting	Panel Mount
Display	Dual 4-digit LED
Input Types	Thermocouple, RTD, mA, mV, V
Output Types	Relay
Power Supply	100-240 VAC, 50/60 Hz
Communication	RS-485 Modbus RTU
Enclosure Rating	NEMA 4X
