WinMax Lathe Conversational Part Programming v546CO Overview 1-5
• NC PROGRAM CALL F6— accesses the NC Program Call data block. Refer
to NC Program Call, on page 2 - 210 for programming information.
• MORE F7—accesses the remaining data block types.
• REPEAT START F1—indicates the start of a block or group of blocks to be
repeated in a part program. Refer to Repeat Start Block, on page 2 - 202
for information.
• REPEAT END F2—indicates the end of a block or group of blocks to be
repeated in a part program. Refer to Repeat Start Block, on page 2 - 202
for information.
• MORE F7—returns to the first set of Miscellaneous softkeys.
• EXIT F8—returns to the first set of part programming softkeys.
• TRANSFER F5—inserts a block for transferring the stock from the Main
spindle to the Sub-spindle. This softkey appears only for TMX MYS series
machines. Refer to Transfer Data Block, on page 2 - 207 for programming
information.
• MOVE TAILSTOCK F5—The data block allows you to move the Z-Axis to the
tailstock and automatically hitch the Z-Axis to the tailstock. Then you can
move the Z-Axis and tailstock together to a specified location at a
programmed feed rate. This softkey appears only for TM12 and TM18 series
machines with the auto-hitch tailstock. Refer to Move Tailstock Data Block, on
page 2 - 206 for programming information.
