WinMax Lathe Conversational Part Programming v546CO Conversational Part Programming 2-199
• TIME ON (SEC)— the amount of seconds the part conveyor or chip conveyor
should run. The default is 0. Use with TIME OFF (SEC) to cycle the conveyor
on and off. This field appears when either M24 (Part Conveyor On) or M50
(Chip Conveyor On) is entered in the M Code field.
• TIME OFF (SEC)—indicates the amount of seconds the part conveyor or chip
conveyor should not run. The default is 0. Use with TIME ON (SEC) to cycle
the conveyor on and off. This field can only be used when a value other than
0 is entered in the TIME ON field. This field appears when either M24 (Part
Conveyor On) or M50 (Chip Conveyor On) is entered in the M Code field.
If the part conveyor or chip conveyor is running at the end of a
program, it will continue running for the specified amount of time.
If cycling, the conveyor will not turn on again if stopped by reaching
the end of the program, Manual Mode is selected, or the enclosure
doors are opened.
If the default value of 0 is used in these fields,
• The part conveyor will run until either the program encounters an
M25 Part Conveyor Off code, Manual Mode is selected, or the
enclosure doors are opened.
• The chip conveyor will run until either the program encounters an
M51 Conveyor Off code, Manual Mode is selected, or the
enclosure doors are opened.
The part conveyor or chip conveyor will stop running if Manual Mode
is selected or the enclosure doors are opened.
