WinMax Lathe Conversational Part Programming v546CO Sample Part Program 3-29
Enter 0.1 for the Radius of the arc.
•The End, Start, and Center locations will be calculated by the control when
the Element following the Blend Arc has been programmed.
•The Finish fields are inactive because Turn Rough is selected in the Profile
Start Process tab.
Figure 3–41. Profile Blend Arc Screen with Radius value
