WinMax Lathe Conversational Part Programming v546CO Conversational Part Programming 2-13
• GOUGE AVOIDANCE—select either YES or NO for the leading and trailing
angles of the insert to be considered as part of the tool path, for example,
turning a thread undercut.
• Select NO and the insert stays inside the programmed geometry when it
moves.
• Select YES and the shape, size, and lead angle of the insert are
considered when the tool path is determined, so the insert avoids the
programmed geometry.
• OPERATION—identifies the type of path, rough or finish, with respect to the
type of tool used for the profile. Refer to Turn Rough Operation, on page 2 -
14, Turn Finish Operation, on page 2 - 17, Groove Rough Operation, on page
2 - 20, or Groove Finish Operation, on page 2 - 22 for programming details.
• TURN ROUGH F1—select if the profile is a rough pass using a turning
tool.
• TURN FINISH F2—select if the profile is a finish pass using a turning
tool.
• GROOVE ROUGH F3—select if the profile is a rough pass using a
grooving tool.
• GROOVE FINISH F4—select if the profile is a finish pass using a grooving
tool.
To create a Finish Profile data block,
1. Program a Rough Profile data block (either Turn or Groove).
2. Select the Menu console button and select Program Review.
3. Highlight the Rough Profile data block.
4. Select the MULTIPLE BLOCK FUNCTIONS F1 softkey.
5. Select the CREATE FINISH PROFILE F7 softkey.
A Finish Profile block is created using the entries in the Rough Profile
block with Turn Finish or Groove Finish entered for the Operation
field.
For more than one finish profile in a data block, repeat the above
steps.
For Turn Finish data blocks, Cutter Compensation is determined
based on the Profile geometry. Stock Allowances are automatically
set to 0.
