viii - Documentation Conventions v546CO WinMax Lathe Conversational Part Programming
• The name of the open, selected program.
• A calculator icon—select the icon to display a working, on-screen calculator.
• Units of measure (Inch or Millimeters)—select the units of measure in the
status bar to toggle between Inch and Metric.
• Programming mode (R for Radius; D for Diameter)—select the programming
mode in the status bar to toggle between Radius and Diameter.
• A yellow icon—indicates the feed hold is on when visible.
• A red icon—indicates the Emergency Stop button has been pressed when
visible.
• A keyboard icon—select the icon to display a working on-screen keyboard.
• The current time.
When viewed on a single-screen console, all icons appear in the same status bar; when
viewed on a dual-screen console, the program name and calculator icon appear on the
left screen status bar, and the unit of measure, keyboard icon and time appear on the
right screen status bar.
Console Buttons and Keys
References to console buttons and keys appear in bold text throughout the
documentation. For example, the Start Cycle button appears as the Start Cycle button
and the Manual key appears as the Manual console key in text.
Refer to the Getting Started with WinMax manual for information about console buttons
and keys, in addition to other information about using softkeys and the pop-up text entry
window.
Using the Touchscreen
The console has a touchscreen for entering programming data. To make a selection, tap
the screen on a softkey, field, or drop-down list using the stylus attached to the side of
the console or another suitable pointing device.
Icons
This manual may contain the following icons:
Caution/Warning
The operator may be injured and/or the machine severely damaged if the
described procedure is not followed.
