3 Setup
301-7146 English Rev B 11/02/2011 Operator’s Manual NA 55
System Configuration Settings
The System Configuration Settings screen is used to select the
presence of microscopy and/or chemistry system, and to choose the
reporting units for the chemistry system.
The user has the possibility to mix conventional and qualitative chemistry
settings for the Iris fully automated chemistry system. These values can
be user-defined in the Chemistry Settings screen. The chemistry settings
can be saved for a primary and a backup chemistry system.
The following options are only available if an iQ Series microscopy
module is connected to the chemistry system:
• Microscopy System Present
• Skip microscopy if no chemistry available
• Consolidation window
• Gate on chemistry
1. Click the appropriate checkbox depending on the laboratory
configuration.
