Juniper SRX650 Hardware Guide

Table 7: SRX650 Services Gateway Front Panel Components (continued)
DescriptionLocationComponentNumber
The High Availability (HA SYS) LED
has the following indicator colors:
•
Green and steadily on indicates
that all configured HA links are
available.
•
Red and steadily on indicates that
the HA links are not working as
expected and a cluster member
might be missing or unreachable.
•
Amber and steadily on indicates
that some configured HA links are
down, but enough links are still
active for full HA functionality. In
this situation, performance might
be reduced, current bandwidth
could cause packet drops, or a
single point of failure might now
exist.
•
Off indicates that HA is not
enabled.
Left side of the
front chassis panel
HA SYS LED9
The Services and Routing Engine
(SRE) 0 LED has the following
indicator colors:
•
Green and steadily on indicates
SRE0 is functioning normally.
•
Amber and steadily on indicates
SRE0 is initializing, performing
diagnostics, or going down.
•
Red and steadily on indicates
SRE0 failure.
•
Off indicates SRE0 slot is empty.
Left side of the
front chassis panel
SRE LED 010
Copyright © 2018, Juniper Networks, Inc.22
SRX650 Services Gateway Hardware Guide
