AKD Installation | 6 Technical description and data
6.2 Ambient Conditions, Ventilation, and Mounting Position
Storage ➜ p. 18
Transport ➜ p. 18
Ambient temperature
in operation
0 to +40 °C under rated conditions
+40 to +55 °C with continuous current derating 4 % per Kelvin
Humidity in operation Relative humidity 5 to 85%, no condensation, class 3K3
Site altitude Up to 1000 meters above mean sea level without restriction
1,000 to 2,500 meters above mean sea level with power der-
ating 1.5%/100 m
Pollution level Pollution level 2 as per IEC 60664-1
Vibrations Class 3M1 according to IEC 60721-3-3
Enclosure protection IP 20 according to IEC 60529
Mounting position Vertical, ➜ p. 61
Ventilation Built-in fan
The drive shuts down (fault F234, ➜ p. 178, motor has no
torque) in case of excessively high temperature in the control
cabinet. Make sure sufficient forced ventilation is supplied
within the control cabinet.
6.3 Mechanical Data
Mechanical data Units AKD
-x00306
AKD
-x00606
AKD
-x01206
AKD
-x02406
Weight (standard width) kg 1.1 2 3.7
Weight (extended width) kg 1.3 2.2 -
Height, without connectors mm 168 196.3 237.7
Height, with connector mm 200 225 280
Standard Width front/back mm 53/59 75.3/78.3 97/100
Extended Width front/back mm 84/89 90/95 -
Depth, without connectors mm 156 187 228
Depth, with connectors mm 185 < 215 <265
Mechanical data Units AKD
-x00307
AKD
-x00607
AKD
-x01207
AKD
-x02407
Weight (standard width) kg 2.7 5.3
Weight (extended width) kg 2.9 -
Height, without connectors mm 256 306
Height, with connector mm 290 340
Standard Width front/back mm 67/70 101.3/105
Extended Width front/back mm 95/100 -
Depth, without connectors mm 185 228
Depth, with connectors mm <225 <265
32 Kollmorgen™ | May 2013
