AKD Installation | 8 Electrical Installation
8.8.2 Connection to Various Mains Supply Networks AKD-xzzz07 (240V to 480V)
This page illustrates all the possible connection variations for different electrical supply net-
works.
There is a danger of electrical shock with serious personnel injury if the
drive is not properly grounded. An isolating transformer is always required
for 120V networks to get a minimum voltage of 240 V +10%.
90 Kollmorgen™ | May 2013
