6.14 Switch-on and Switch-off Behavior
This chapter describes the switch-on and switch-off behavior of the AKD.
Behavior of “holding brake” function
Drives with an enabled holding brake function have a special timing for switching on and off
the output stage (➜ p. 102). Events that remove the DRV.ACTIVE signal trigger the holding
brake to apply. As with all electronic circuits, the general rule applies that there is a pos-
sibility of the internal holding brake module failing.
Functional safety, e.g. with hanging load (vertical axes), requires an additional mechanical
brake which must be safely operated, for example by a safety control.
If velocity drops below threshold CS.VTHRESH or timeout occurs during a stop procedure,
the brake is applied. Set parameter MOTOR.BRAKEIMM to 1 with vertical axes, to apply the
motor holding brake (➜ p. 102) immediately after faults or Hardware Disable.
Behavior when undervoltage condition is present
The behavior in an undervoltage condition depends on the VBUS.UVMODE setting.
VBUS.UVMODE DC Bus Undervoltage Mode. Consult the AKDUser Guide for con-
figuring the parameter.
0 The drive will report a F502 undervoltage fault any time an undervoltage
condition occurs.
1 (default) The drive will report a warning n502 if not enabled. The drive will report a
fault if the drive is enabled when the condition occurs, or an attempt is
made to enable while an under voltage condition occurs.
Safety function STO
With the personnel safe function STO, the drive can be secured on standstill using its inter-
nal electronics so that even when power is being supplied, the drive shaft is protected
against unintentional restart. The chapter “Safe Torque Off (STO)” describes how to use the
STO function (➜ p. 52).
AKD Installation | 6 Technical description and data
Kollmorgen™ | May 2013 43
