6.6 Electrical Data AKD-xzzz07
Electrical data Units
AKD-
x00307
AKD-
x00607
AKD-
x01207
AKD-
x02407
Rated supply voltage V 3 x 240 V to 480 V ±10%
Rated supply input frequency Hz AC with 50 Hz to 400 Hz ±5% or DC
Rated input power for S1 operation kVA 2.24 4.49 7.65 15.2
Rated input current
at 3x240 V A 2.7 5.4 9.2 18.3
at 3x400 V A 2.7 5.4 9.2 18.3
at 3x480 V A 2.7 5.4 9.2 18.3
Permitted switch on/off frequency 1/h 30
Max. inrush current A 10 10 10 20
Rated DC bus link voltage
(Bus Turn on Delay 3ph 1 sec)
V= 340 to 680
Continuous output current (± 3%)
at 240 V Arms 3 6 12 24
at 400 V Arms 3 6 12 24
at 480 V Arms 3 6 12 24
Peak output current (for 5 s, ± 3%) Arms 9 18 30 48
Continuous output power
at 3x240 V kVA 0.6 1.25 2.5 5
at 3x400 V kVA 1 2 4.2 8.3
at 3x480 V kVA 1.2 2.5 5 10
Peak output power (for 1 s)
at 3x240 V kVA 1.8 3.75 6.25 10
at 3x400 V kVA 3 6.75 10.4 16.7
at 3x480 V kVA 3.6 7.5 12.5 20
Technical data for regen circuit — ➜ p. 40
Motor inductance min.
at 240 V mH 3.2 1.6 1.3 0.6
at 400 V mH 5.3 2.6 2.1 1
at 480 V mH 6.3 3.2 2.5 1.2
Motor inductance max. mH 600 300 250 120
Thermal dissipation, output stage disable W max. 20 max. 20 max. 20 max. 25
Thermal dissipation at rated current W 102 129 153 237
Noise emission (low speed/high speed fan)
dB
(A)
34/43 34/43 44/52 48/58
Aux. voltage supply V= 24 V (±10%, check voltage drop)
-current B, P, T types without/with motor brake A= 1 / 2.5 1 / 2.5 1 / 2.5 2 / 4
-current M type without/with motor brake A= 1.3 / 2.8 1.3 / 2.8 1.3 / 2.8 -
AKD Installation | 6 Technical description and data
Kollmorgen™ | May 2013 35

Kollmorgen AKD Specifications

General

Control Modes	Torque, Velocity, Position
Communication Interfaces	EtherCAT, CANopen
Feedback Options	Resolver
Safety	STO (Safe Torque Off), SS1 (Safe Stop 1)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature
Operating Temperature Range	0°C to 55°C
Humidity	5% to 95% non-condensing
