4.1 Basic Operation
127
Chapter 4
Button Functions
[Store]
Executes the store still image or clip function. You can assign functions according to the
settings.
[BW Print] Executes the BW print function.
[Still Store] Executes the still image store function.
[Clip Store] Executes the clip store function.
[Cine Clip Store] Executes the Cine clip store function.
[Trackball] Displays the software trackball.
[TGC] Opens the TGC menu.
[Simple Adjust] Executes the Simple Adjust function.
[Zoom] Zooms an image.
[Parameter Display] Displays parameters on each screen during dual mode.
[TD Guide]
Executes the transducer guide function.
Becomes operative when a linear transducer has been attached to the system.
[S.Adjust Quit] Deactivates the Simple Adjust function.
[D Angle] Sets the Doppler angle to 60°, 0°, or -60°.
[ECG]
Displays to overlay the bright line of an ECG (electrocardiogram) on an ultrasound im-
age.
• To use this function, an optional "Reference Signal Unit" is required.
[RA Work Flow]
Starts up the RA Work Flow function.
• To use this function, "RA Work Flow License" is required.
[Report] Starts up the Report function.
[Worksheet] Starts up the Worksheet function.
[Joblist]
The [Joblist] screen appears to allow you to check the status of transmission to the
DICOM storage server.
[Export Image]
The [Export Image] screen appears, allowing you to write image data to an SD memory
card.
[Full Screen] Starts up full screen display mode.
[Touch Disable] Starts up Touch O mode.
[Graph]
Starts up the Graph function.
• To use this function, "OB Report License" is required.
[Description]
Starts up the Description function.
• To use this function, "OB Report License" is required.
[MPA Customize]
Displays the MPA Customize pop-up menu.
You can create a combination of multiple parameters according to depth as an MPA. Set
the parameters while changing the depth, just like normal parameter operations.
Tap [Utility] to store the settings.
You can display the MPA that you created as an operation button.
(
MPA that was created) Set parameters using the values for the MPA that you created.
[Library]
Starts up the Library function.
• To use this function, "Library License" or "Direct Recording License" is required.
[Voice Control]
Starts up the Voice Control function.
• To use this function, "Voice Control License" is required.
[Panoramic View]
Starts up the Panoramic View.
• To use this function, "Panoramic View License" is required.
Continued on the next page
To Next Page
