4.1 Basic Operation
128
Button Functions
[Transducer]
Every time you press the button during an exam, you can change the port that is con-
nected to the transducer (Port1→ Port2→ Port3).
Ports to which no transducer is attached are skipped, and if only one transducer is con-
nected, the button does not operate even if it is pressed.
[Direct Store]
Saves still images and clips to external media.
• To use this function, "Direct Recording License" is required.
[Direct Still Store]
The image when the button was pressed is stored to external media.
• To use this function, "Direct Recording License" is required.
[Direct Clip Store]
*
Recording of the clip starts and the captured clip is stored to external media.
• To use this function, "Direct Recording License" is required.
[Direct Cine Clip Store]
The clip generated from the cine data is stored to external media.
• To use this function, "Direct Recording License" is required.
[HyRC]
Starts up the Hypoechoic Region Characterization function.
• To use this function, "Hypoechoic Region Characterization License" is required.
*
: The length (time) of the clip may not reach the set time, depending on the clip being stored.
Use input/output ports and media with fast transmission speeds and media with fast writing speeds.
There are also limits on the size of les that can be stored in FAT16 format and FAT32 format. If the length (time) of the clip ex-
ceeds the size limit, then only the time up to the size limit is stored.
