7.2 Maintenance Check and Cleaning
z
Cleaning the trackball
• Materials used: Dry cloth or tissue
1
Turn the trackball ring counterclockwise and remove it.
Trackball ring
2
Remove the trackball retainer from the trackball ring.
Trackball ring
Trackball retainer
Removed
3
Clean the both sides and whole circumference of the trackball retainer.
