Kyocera FS-C8600DN - Page 103

2MN/2N1
1-3-35
U034 5. Change the setting value using the numeric keys.
For output example 1, increase the value. For output example 2, decrease the value.
Figure 1-3-5
6. Press the OK key. The value is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Center line of printing
(within ± 2.0 mm)
Correct image
Output
example 1
Output
example 2
