Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-47
U059 Setting fan mode
Description
Specifies mode for developer fan motors.
Purpose
Handling the lowering density [to suppress thermal stresses owing to the heated toner]
Method
1. Press the OK key.
2. Select the mode.
Setting: [Fan]
1. Select the mode.
Initial setting: Mode1
2. Press the OK key. The setting is set.
Setting: [Cooling]
1. Change the setting value using the numeric keys.
A larger value advances the operating timing, and a smaller value slows it.
2. Press the OK key. The value is set.
Completion
Press the Back key. The indication for selecting a maintenance item No. appears.
Item No. Description
Display Description
Fan Sets threshold temperature at which developer fan motors oper-
ate.
Cooling Sets temperature at which the developer fan motors are switched
for controlling.
Display Description
Mode1 Setting temperature:Normal
Mode2 Setting temperature:Temperature threshold is raised from mode1
(WUP, temperature at READY : mode1 temperature -7(°C), Tempera-
ture at PRINT : mode1 temperature -3(°C).)
Mode3 Setting temperature:Temperature threshold is raised from mode2
(WUP, temperature at READY : mode1 temperature -22(°C), Temper-
ature at PRINT : mode1 temperature -8(°C).)
Auto Starting with Mode 2 at power up or recovery from sleep mode, and
switches to Mode 3 when the termistor detects a developer tempera-
ture BK is equal to or higher than 38°C. The device never reverts
from mode 2 from mode 3 while power is on.
Display Description
Setting
range
Initial
setting
Cooling Mode Amount of shift from the initial standard
temperature
-3 to 3 (°C) 0

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
