Kyocera FS-C8600DN - Paper Conveying Sensor Non Arrival Jam; Paper Conveying Sensor Stay Jam; PF Paper Conveying Sensor 1 Stay Jam; PF Paper Conveying Sensor 2 Non Arrival Jam

2MN/2N1
1-4-7
1502 Paper conveying sensor
non arrival jam
Paper conveying sensor (PCS) does not turn on during
paper feed from cassette 2.
B
1503 Paper conveying sensor (PCS) does not turn on during
paper feed from cassette 3 (paper feeder/large capac-
ity feeder).
C
1504 Paper conveying sensor (PCS) does not turn on during
paper feed from cassette 4 (paper feeder/large capac-
ity feeder).
C
1512 Paper conveying sensor
stay jam
Paper conveying sensor (PCS) does not turn off during
paper feed from cassette 2.
E
1513 Paper conveying sensor (PCS) does not turn off during
paper feed from cassette 3 (paper feeder/large capac-
ity feeder).
E
1514 Paper conveying sensor (PCS) does not turn off during
paper feed from cassette 4 (paper feeder/large capac-
ity feeder).
E
1703 PF paper conveying sen-
sor 1 non arrival jam
PF paper conveying sensor 1 (PFPCS1) does not turn
on during paper feed from cassette 3 (paper feeder).
C
1704 PF paper conveying sensor 1 (PFPCS1) does not turn
on during paper feed from cassette 4 (paper feeder).
C
1713 PF paper conveying sen-
sor 1 stay jam
PF paper conveying sensor 1 (PFPCS1) does not turn
off during paper feed from cassette 3 (paper feeder).
E
1714 PF paper conveying sensor 1 (PFPCS1) does not turn
off during paper feed from cassette 4 (paper feeder).
E
1904 PF paper conveying sen-
sor 2 non arrival jam
PF paper conveying sensor 2 (PFPCS2) does not turn
on during paper feed from cassette 4 (paper feeder).
C
1914 PF paper conveying sen-
sor 2 stay jam
PF paper conveying sensor 2 (PFPCS2) does not turn
off during paper feed from cassette 4 (paper feeder).
E
2106 PF paper conveying sen-
sor 1 non arrival jam
PF paper conveying sensor 1 (PFPCS1) does not turn
on during paper feed from cassette 6 (side paper
feeder).
K
2107 PF paper conveying sensor 1 (PFPCS1) does not turn
on during paper feed from cassette 7 (side paper
feeder).
K
2116 PF paper conveying sen-
sor 1 stay jam
PF paper conveying sensor 1 (PFPCS1) does not turn
off during paper feed from cassette 6 (side paper
feeder).
J
2117 PF paper conveying sensor 1 (PFPCS1) does not turn
off during paper feed from cassette 7 (side paper
feeder).
J
2307 PF paper conveying sen-
sor 2 non arrival jam
PF paper conveying sensor 2 (PFPCS2) does not turn
on during paper feed from cassette 7 (side paper
feeder).
K
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-1 for paper misfeed indication (see page 1-4-1).
