Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-78
U147 Setting for toner applying operation
Description
Sets the mode for removing charged toner in the developing unit (T7 control: Toner applying
operation). Defines the action that the toner accumulated on the developer blade is sent back in
the developer unit (done by the vibration motor).
Purpose
The setting can be changed to reduce the toner applying quantity. Performed to change the
occurrence of the control of the vibration motor.
If the charged toner stays inside the developing unit, density decreases.
Method
1. Press the OK key.
2. Select the item to be set.
Setting: [Mode]
1. Select the mode.
Initial setting; Mode1
2. Press the OK key. The setting is set.
Setting: [Upper Limit]
1. Change the setting value using the numeric keys.
2. Press the OK key. The value is set.
Setting: [Minimum]
1. Change the setting value using the numeric keys.
2. Press the OK key. The value is set.
Item No. Description
Display Description
Mode Settings for toner applying operation
Upper Limit Upper limit printing ratio of toner applying quantity with each mode
Minimum Toner layer width when cleaning mode is selected
Interval Number Setting the vibration motor On timing
Display Description
Mode0 Less consumption of toner than a regular toner applying operation
Mode1 Executes toner applying with the regular amount of toner
Mode2 Applying more consumption of toner than a regular toner applying
operation
Display Description
Setting
range
Initial
setting
Value Upper limit printing ratio of toner applying
quantity with each mode (%)
0 to 2.0 2.0
Display Description
Setting
range
Initial
setting
Value Toner layer width when cleaning mode is
selected (mm)
0 to 30 10

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
