Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-4-59
7003 Toner motor M error
When the toner motor K is
driven, the pulse sensor is not
detected for 15 times in 200
ms intervals has occurred in
15 times.
During the toner motor is
driven, an event in which
TMOT_LOCK turns to H
(locked) 5 times has occurred
in 15 sets.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Toner motor M and engine PWB (YC27)
Defective screw
sensor M.
Replace the screw sensor M.
Defective toner
motor M.
Replace the toner motor M.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
7004 Toner motor Y error
When the toner motor K is
driven, the pulse sensor is not
detected for 15 times in 200
ms intervals has occurred in
15 times.
During the toner motor is
driven, an event in which
TMOT_LOCK turns to H
(locked) 5 times has occurred
in 15 sets.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Toner motor Y and engine PWB (YC27)
Defective screw
sensor Y.
Replace the screw sensor Y.
Defective toner
motor Y.
Replace the toner motor Y.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
7101 Toner sensor K error
Sensor output value of 60 or
less or 944 or more continued
for 3 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Toner sensor K and front PWB (YC9)
Front PWB (YC2) and engine PWB (YC10)
Defective toner
sensor K.
Replace developer unit K (see page 1-5-29).
Failure of locking
the developer
waste slot at setup.
Check whether the developer waste slot has
been unlocked and unlock if necessary (see
page 1-2-14).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
