Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-148
U964 Checking of log
Description
Sends a log file saved on the HDD to a USB memory.
Purpose
To transfer a log file saved on the HDD to a USB memory as a means of investigating malfunc-
tions.
Method
1. Perform shut-down on the operation panel, turn power off(see page P.1-2-19).
2. Insert USB memory in USB memory slot.
3. Turn the main power switch on.
4. Enter maintenance item U964.
5. Select [Execute].
6. Press the OK key.
Starts sending the log file saved on the HDD to the USB memory.
Processing is displayed for approximately 3 to 5 minutes.
7. When normally completed, [Completed] is displayed.
8. Exit the maintenance mode, perform shut-down, and turn the main power switch to off and on
again. Allow more than 5 seconds between Off and On.
If a problem occurs during auto correction, error code is displayed.
Error codes
U969 Checking of toner area code
Description
Displays the toner area code.
Purpose
To check the toner area code.
Method
1. Press the OK key. The toner area code is displayed.
Completion
Press the stop/clear key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Error codes Error name Description
1 No Usb Storage USB memory is not inserted
2 No File File is not found
3 Mount Error USB memory mount error
4 File Delete Error File deletion error
5 Copy Error File copy error
6 Unmount Error USB memory unmount error
7 Other Error Other error
