Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-118
U464 Setting the ID correction operation
Description
Turns ID correction (calibration) on or off. Also, this allows individual settings for calibration oper-
ation.
Purpose
Implements various settings of calibration when poor image quality is caused or to allow various
settings of calibration depending on the user preference.
To perform the calibration when replacing the maintenance kit.
Method
1. Press the OK key.
1. Select the item to be set.
2. Press the OK key.
*: Enabled when Mode is set to Custom.
Setting: [Permission]
1. Select On or Off.
Initial setting: On
2. Press the OK key. The setting is set.
Item No. Description
Display Description
Permission Setting to turn calibration on/off
Time Interval Setting the interval time of calibration after printing
Mode Setting the color print execution mode
On/Sleep Out*
Setting execution parameters for calibration when powered up
or reverted from auto-sleep
AP/NE* Paper interval calibration ON/OFF setting at the time of cali-
bration/near end after toner feed
Leaving Time* Setting the standard time for judging whether or not to carry
out calibration based on the sleep time when the machine
recovers from the sleep mode
Driving Time* Setting the standard time for judging whether or not to carry
out paper interval calibration based on the driving time during
printing
Timing* Setting the standard time for judging whether or not to carry
out calibration based on the continuous print driving time dur-
ing printing
Target Value Setting the sensor target values for toner thick layer calibration
and light amount calibration
Print Rate(B/W)* Setting the proportion of black/white printing at which black/
white calibration is executed during color printing.
Calib Executing the calibration
Edge Reduction Smoothing edge settings (automatic calibration is imple-
mented after settings are completed)
Display Description
On Turns calibration ON
Off Turns calibration OFF
