Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-102
U247 Setting the paper feed device
Description
Turns on motor and clutches of paper feeder device.
Purpose
To check the operation of motor and clutches of paper feed device.
Method
1. Press the OK key.
2. Select the paper feed device.
Method: [2PF/Side 2PF]
1. Press the OK key.
2. Select [Motor] or [Device].
3. Select the item to be operated using the Left/Right Select keys.
4. Select [Execute].
5. Press the OK key. The operation starts.
6. To stop operation, press the Back key.
Item No. Description
Display Description
2PF Paper feeder
LCF Large capacity feeder
Side Deck Side deck
SMT Side multi tray
Side 2PF Side paper feeder
Side LCF Side large capacity feeder
Display Description
Motor Off PF paper feed motor (PFPFM) is turned off
On PF paper feed motor (PFPFM) is turned on
Device C1 Clutch PF paper conveying clutch 1 (PFPCCL1) is turned on
C2 Clutch PF paper conveying clutch 2 (PFPCCL2) is turned on
V Feed(H) Clutch PF paper feed clutch 1 (PFPFCL1) is turned on
V Feed(L) Clutch PF paper feed clutch 2 (PFPFCL2) is turned on
Cassette1 Solenoid PF pickup solenoid 1 (PFPUSOL1) is turned on
Cassette2 Solenoid PF pickup solenoid 2 (PFPUSOL2) is turned on

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
