Kyocera FS-C8600DN - Broken LSU Thermistor K Wire; Broken Outer Temperature Sensor 2 Wire; Short-Circuited Outer Temperature Sensor 2

2MN/2N1
1-4-61
7200 Broken outer temperature
sensor 2 wire
The sensor input sampling is
greater than 230.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Outer temperature sensor 2 and front PWB
(YC19)
Front PWB (YC2) and engine PWB (YC10)
Defective outer
temperature sen-
sor 2.
Replace outer temperature sensor 2.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
7210 Short-circuited outer tem-
perature sensor 2
The sensor input sampling is
less than 69.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Outer temperature sensor 2 and front PWB
(YC19)
Front PWB (YC2) and engine PWB (YC10)
Defective outer
temperature sen-
sor 2.
Replace outer temperature sensor 2.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
7221 Broken LSU thermistor K
wire
The sensor input sampling is
greater than 230.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Laser scanner unit and LSU relay PWB
(YC5)
LSU relay PWB (YC3) and engine PWB
(YC12)
Defective LSU
thermistor K.
Replace the laser scanner unit (see page 1-
5-17).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
Code Contents Causes
Check procedures/
corrective measures
