Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-51
5103 Main high-voltage error M
Measure the inflowing current
when Vpp is varied in 3 steps
and verify if the difference of
the currents of 0 and step 2 is
less than 42 (51 if lower high-
voltage board).
Improper installa-
tion charger roller
unit M.
Reinstall the charger roller unit M.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
High voltage PWB 1 (YC3) and engine PWB
(YC17)
Defective high volt-
age PWB 1.
Replace the high voltage PWB 1 and check
for correct operation (see page 1-5-54).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
5104 Main high-voltage error Y
Measure the inflowing current
when Vpp is varied in 3 steps
and verify if the difference of
the currents of 0 and step 2 is
less than 42 (51 if lower high-
voltage board).
Improper installa-
tion charger roller
unit Y.
Reinstall the charger roller unit Y.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
High voltage PWB 1 (YC1) and engine PWB
(YC16)
Defective high volt-
age PWB 1.
Replace the high voltage PWB 1 and check
for correct operation (see page 1-5-54).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
6000 Broken fuser heater wire
Fuser thermistor 1 does not
reach 100° C/212 °F even
after 60 s during warming up.
The detected temperature of
fuser thermistor 1 does not
reach the specified tempera-
ture (ready indication temper-
ature) for 420 s in warming up
after reached to 100° C/212
°F.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Power source PWB (YC3) and fuser IH PWB
(YC1)
Fuser IH PWB (YC4) and engine PWB
(YC26)
Fuser thermostat
triggered.
Replace the fuser unit (see page 1-5-40).
Defective fuser IH. Replace the fuser unit (see page 1-5-40).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
6020 Abnormally high fuser
thermistor 1 temperature
Fuser thermistor 1 detects a
temperature higher than
240°C/464°F for 1 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Fuser unit and engine PWB (YC26)
Shorted fuser
thermistor 1.
Replace the fuser unit (see page 1-5-40).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
