Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-81
U156 Setting the toner replenishment level
Description
Sets the toner replenishment level for each color.
Purpose
To change settings according to the original image.
Method
1. Press the OK key.
2. Select the item to be set.
Method: [Supply]
1. Select the item to be set.
2. Change the setting value using the numeric keys.
Increasing the setting makes the image lighter; decreasing it makes the image darker.
*: 55 ppm model only.
3. Press the OK key. The value is set.
Method: [Empty]
1. Select the item to be set.
2. Change the setting value using the numeric keys.
Increasing the setting makes ‘toner empty’ appear later and decreasing it makes ‘toner
empty’ appear earlier.
*: 55 ppm model only.
3. Press the OK key. The value is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Supply Setting the toner replenishment level
Empty Setting the toner empty level
Display Description
Setting
range
Initial
setting
C Toner replenishment level for cyan 0 to 900 512
M Toner replenishment level for magenta 0 to 900 512
Y Toner replenishment level for yellow 0 to 900 512
K Toner replenishment level for black 0 to 900 512
B/W* Toner replenishment level in black/white mode 0 to 900 512
Display Description
Setting
range
Initial
setting
C Toner empty level for cyan 0 to 1023 100
M Toner empty level for magenta 0 to 1023 100
Y Toner empty level for yellow 0 to 1023 100
K Toner empty level for black 0 to 1023 100
B/W* Toner empty level in black/white mode 0 to 1023 100

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
