Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-96
(21)
Paper conveying
clutch does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Paper conveying clutch and feed PWB 2 (YC5)
Feed PWB 2 (YC1) and engine PWB (YC4)
2. Defective clutch. Replace the paper conveying clutch.
3. Defective PWB. Replace the feed PWB 2 or engine PWB and check for cor-
rect operation (see page 1-5-49).
(22)
MP paper feed
clutch does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
MP paper feed clutch and relay PWB (YC3)
Relay PWB (YC12) and feed PWB 1 (YC17)
Feed PWB 1 (YC1) and engine PWB (YC6)
2. Defective clutch. Replace the MP paper feed clutch.
3. Defective PWB. Replace the relay PWB, feed PWB 1 or engine PWB and
check for correct operation (see page 1-5-49).
(23)
Pickup solenoid 1,
2 does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Pickup solenoid 1, 2 and feed PWB 2 (YC8)
Feed PWB 2 (YC1) and engine PWB (YC4)
2. Defective solenoid. Replace the pickup solenoid 1 or 2.
3. Defective PWB. Replace the feed PWB 2 or engine PWB and check for cor-
rect operation (see page 1-5-49).
(24)
Feedshift solenoid
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Feedshift and front PWB (YC5)
Front PWB (YC3) and engine PWB (YC7)
2. Defective solenoid. Replace the feedshift solenoid 1 or 2.
3. Defective PWB. Replace the front PWB or engine PWB and check for cor-
rect operation (see page 1-5-49).
(25)
Cleaning solenoid
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Cleaning solenoid and feed PWB 1 (YC10)
Feed PWB 1 (YC1) and engine PWB (YC4)
2. Defective solenoid. Replace the cleaning solenoid.
3. Defective PWB. Replace the feed PWB 1 or engine PWB and check for cor-
rect operation (see page 1-5-49).
(26)
The message
requesting paper to
be loaded is shown
when paper is
present on the cas-
sette.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Paper sensor 1, 2 and feed PWB 2 (YC8)
Feed PWB 2 (YC1) and engine PWB (YC4)
2. Deformed actuator. Check visually and replace if necessary.
3. Defective sensor. Replace the paper sensor 1 or 2.
4. Defective PWB. Replace the feed PWB 2 or engine PWB and check for cor-
rect operation (see page 1-5-49).
Problem Causes Check procedures/corrective measures

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
