Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-1-1
1-1 Specifi cations
1-1-1 Specifications
Machine
Item
Specifications
45 ppm 55 ppm
Type Desktop
Printing method Electrophotography by semiconductor laser, tandem drum system
Paper weight
Cassette 60 to 256 g/m
2
MP tray 60 to 300 g/m
2
Paper type
Cassette
Plain, Rough, Vellum, Recycled, Preprinted, Bond, Color (Colour),
Prepunched, Letterhead, Thick, High Quality, Custom 1 to 8
(Duplex: Same as simplex)
MP tray
Plain, Transparency (OHP film), Rough, Vellum, Labels, Recycled,
Preprinted, Bond, Cardstock, Color (Colour), Prepunched, Letterhead,
Thick, Coated, Envelope, High Quality, Custom 1 to 8
Paper size
Cassette
A3, B4, A4, A4R, B5, B5R, A5R, Ledger, Legal, Letter, LetterR,
StatementR, Oficio II, 12 × 18", Folio, 8K, 16K, 16KR
MP tray
A3, B4, A4, A4R, B5, ISO B5, B5R, A5R, B6R, A6R, Return postcard,
Postcards, Envelope DL, Envelope C5, Envelope C4, Envelope #10
(Commercial #10), Envelope #9 (Commercial #9), Envelope #6
(Commercial #6 3/4), Envelope Monarch, Youkei 2, Youkei 4, Ledger,
Legal, Letter, LetterR, Executive, StatementR, Oficio II, 12 × 18", Folio,
8K, 16K, 16KR, Custom (98× 148mm × 304.9 × 1219.2mm)
Printing
speed
B/W
A4 : 45 ppm
Letter : 45 ppm
A4R : 24 ppm
LetterR : 24 ppm
A3 : 22 ppm
Ledger : 22 ppm
B4 : 27 ppm
Legal : 21 ppm
B5 : 45 ppm
A4 : 55 ppm
Letter : 55 ppm
A4R : 24 ppm
LetterR : 24 ppm
A3 : 27 ppm
Ledger : 27 ppm
B4 : 33 ppm
Legal : 21 ppm
B5 : 55 ppm
Color
A4 : 45 ppm
Letter : 45 ppm
A4R : 24 ppm
LetterR : 24 ppm
A3 : 22 ppm
Ledger : 22 ppm
B4 : 27 ppm
Legal : 21 ppm
B5 : 45 ppm
A4 : 50 ppm
Letter : 50 ppm
A4R : 24 ppm
LetterR : 24 ppm
A3 : 25 ppm
Ledger : 25 ppm
B4 : 30 ppm
Legal : 21 ppm
B5 : 50 ppm
First print
time
(A4, feed from
cassette)
B/W
5.4 s or less
4.9 s or less
Color
6.6 s or less
6.2 s or less

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
