Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-57
6900 Fuser belt cooling fan error
When the fuser edge fan
motor 1 , 2 is driven, alarm
signal is detected for 5 s con-
tinuously.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Fuser edge fan motor 1 and front PWB
(YC26)
Fuser edge fan motor 2 and fuser PWB
(YC2)
Fuser PWB (YC1) and engine PWB (YC26)
Defective fuser
edge fan motor 1
or 2.
Replace the fuser edge fan motor 1 or 2.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
6910 Engine software ready error
The device won’t engage in
ready state in 60 minutes after
warming-up has began.
Defective engine
software.
Install the engine software.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation(see page 1-5-49).
6920 Fuser front fan motor error
When the fuser front fan
motor is driven, alarm signal is
detected for 5 s continuously.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Fuser front fan motor and engine PWB
(YC26)
Defective fuser
front fan motor.
Replace fuser front fan motor.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
6930 Fuser rear fan motor error
When the fuser rear fan motor
is driven, alarm signal is
detected for 5 s continuously.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
Fuser rear fan motor and fuser PWB (YC2)
Fuser PWB (YC1) and engine PWB (YC26)
Defective fuser
rear fan motor.
Replace fuser rear fan motor.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
6940 IH fan motor error
When the IH fan motor is
driven, the alarm signal is
detected for 5 s continuously.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
IH fan motor and feed PWB 1 (YC11)
Feed PWB 1 (YC2) and engine PWB (YC5)
Defective IH fan
motor.
Replace the IH fan motor.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
