Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-4-71
8020 Punch motor error 2
Home position is not obtained
in 3 s after home position is
initialized or in standby.
Defective connec-
tor cable or poor
contact in the con-
nector (4000-sheet
finisher).
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Punch motor and punch PWB (YC4)
Punch PWB (YC1) and DF main PWB (YC7)
Defective connec-
tor cable or poor
contact in the con-
nector (1000-sheet
finisher).
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Punch motor and punch PWB (YC4)
Punch PWB (YC1) and DF main PWB (YC8)
Defective punch
motor.
Replace the punch motor.
Defective PWB. Replace the punch PWB or DF main PWB
and check for correct operation.
8030 Punch motor error 3
Home position does not turn
from On to Off in 50 ms after
home position has been ini-
tialized.
Defective connec-
tor cable or poor
contact in the con-
nector (4000-sheet
finisher).
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Punch motor and punch PWB (YC4)
Punch PWB (YC1) and DF main PWB (YC7)
Defective connec-
tor cable or poor
contact in the con-
nector (1000-sheet
finisher).
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Punch motor and punch PWB (YC4)
Punch PWB (YC1) and DF main PWB (YC8)
Defective punch
motor.
Replace the punch motor.
Defective PWB. Replace the punch PWB or DF main PWB
and check for correct operation.
8040
Abnormal simultaneous
connection of mailbox
When the mailbox is installed
in both the main unit and the
finisher.
When the mailbox
is installed in both
the main unit and
the finisher.
Uninstall either of the mailboxes.
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
