Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-24
6400 DF tray upper surface
sensor non arrival jam
DF tray upper surface sensor (DFTUSS) does not turn
on within specified time of DF middle eject sensor
(DFMES) turning on (4000-sheet finisher).
H
6401 DF tray upper surface sensor (DFTUSS) does not turn
on within specified time of DF middle eject sensor
(DFMES) turning on (1000-sheet finisher).
H
6410 DF tray upper surface
sensor stay jam
DF tray upper surface sensor (DFTUSS) is not turned
off within specified time of its turning on (4000-sheet
finisher).
H
6411 DF tray upper surface sensor (DFTUSS) is not turned
off within specified time of its turning on (1000-sheet
finisher).
H
6500 DF bundle discharge
sensor non arrival jam
DF bundle discharge sensor (DFBDS) does not turn on
within specified time of DF middle eject sensor
(DFMES) turning on.
H
6510 DF bundle discharge
sensor stay jam
DF bundle discharge sensor (DFBDS) is not turned off
since the bundle discharge starts (4000-sheet finisher).
H
6511 DF bundle discharge sensor (DFBDS) is not turned off
since the bundle discharge starts (1000-sheet finisher).
H
6600 DF drum sensor non
arrival jam
DF drum sensor (DFDRS) does not turn on within
specified time of DF paper entry sensor (DFPES) turn-
ing on.
H
6610 DF drum sensor stay jam DF drum sensor (DFDRS) is not turned off within spec-
ified time of its turning on.
H
6710 Center folding unit stay
jam
During paper conveying to center folding unit, DF drum
sensor (DFDRS) is not turned off within specified time
of its turning on.
H
6810 DF side registration sen-
sor 1 stay jam
DF side registration sensor 1 (DFSRS1) is not turned
off within specified time after driving the DF side regis-
tration motor 1 (DFSRM1) (4000-sheet finisher).
H
6811 DF side registration sensor 1 (DFSRS1) is not turned
off within specified time after driving the DF side regis-
tration motor 1 (DFSRM1) (1000-sheet finisher).
H
6910 DF side registration sen-
sor 2 stay jam
DF side registration sensor 2 (DFSRS2) is not turned
off within specified time after driving the DF side regis-
tration motor 2 (DFSRM2) (4000-sheet finisher).
H
6811 DF side registration sensor 2 (DFSRS2) is not turned
off within specified time after driving the DF side regis-
tration motor 2 (DFSRM2) (1000-sheet finisher).
H
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-1 for paper misfeed indication (see page 1-4-1).

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
