Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-124
U467 Setting the color registration adjustment
Description
Sets the color registration adjustment and transfer belt speed correction. Also, determines the
conditions by which color registration correction is executed depending on the LSU temperature.
Purpose
If color variance is uneven due to a sensor failure, etc., turn this off and temporarily make a man-
ual adjustment.
Method
1. Press the OK key.
2. Select the item to be set.
Setting: [Color Regist]
1. Select On or Off.
Initial setting: On
2. Press the OK key. The setting is set.
Setting: [Timing]
1. Change the setting value using the numeric keys.
2. Press the OK key. The value is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Color Regist Setting the color registration correction operation
Timing After the previous correction is executed, color registration is
compensated as the LSU temperature varies by the value
determined.
Display Description
On Enables the color registration correction operation.
Off Disables the color registration correction operation.
Display Description
Setting
range
Initial
setting
LSU Temp Conditions for execution depending on
the LSU temperature variation
2 to 10 10
