Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-45
2850 Transfer belt motor sensor
error
The signal is not received for
100 ms in succession.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Transfer motor and feed PWB (YC13)
Feed PWB (YC1) to engine PWB(YC6)
Defective transfer
motor.
Replace the transfer motor.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
2860 Transfer belt sensor error
The signal is not received for
100 ms in succession.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Transfer belt sensor and engine PWB (YC3)
Defective transfer
belt sensor.
Replace the transfer belt sensor.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
2950 Motor control PWB commu-
nication error
A communication error from
the motor control PWB is
detected 10 times in succes-
sion.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Motor control PWB (YC3) and engine PWB
(YC9)
Defective motor
control PWB.
Replace the motor control PWB and check
for correct operation.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
4001 Polygon motor K synchroni-
zation error
After polygon motor K is
driven, the ready signal does
not turn to L within 30 s.
The polygon motor speed
won’t stabilize within 10 s.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Polygon motor K and LSU relay PWB (YC4)
LSU relay PWB (YC4) and engine PWB
(YC12)
Defective polygon
motor K.
Replace the laser scanner unit (see page 1-
5-17).
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
