Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-33
1250 SM multi feed sensor com-
munication error (side multi
tray)
A communication error is
detected 3 times in succes-
sion.
Improper installa-
tion side multi tray.
Follow installation instruction carefully again.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
SM main PWB (YC1) and engine PWB
(YC19)
Defective engine
PWB.
Replace the engine PWB a1-5-49nd check
for correct operation (see page 1-5-49).
Defective SM main
PWB.
Replace the SM main PWB (Refer to the
service manual for the paper feeder).
1350 SM multi feed sensor error
(side multi tray)
The SM multi feed sensor has
detected multi feeding 5 times
successively.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
SM multi feed sensor and SM main PWB
(YC11)
Defective SM multi
feed sensor.
Replace the SM multi feed sensor.
Defective SM main
PWB.
Replace the SM main PWB (Refer to the
service manual for the paper feeder).
1450 SM multi feed sensor
backup error
(side multi tray)
When writing the data, read
and write data does not match
3 times in succession.
Deleting a block has failed
three times in a row.
Writing won’t complete in 200
ms after writing has com-
menced.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
SM multi feed sensor and SM main PWB
(YC11)
Defective SM multi
feed sensor.
Replace the SM multi feed sensor.
Defective SM main
PWB.
Replace the SM main PWB (Refer to the
service manual for the paper feeder).
1800 Paper feeder communica-
tion error
A communication error from
paper feeder is detected 10
times in succession.
Improper installa-
tion paper feeder.
Follow installation instruction carefully again.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF main PWB (YC13) and engine PWB
(YC19)
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-49).
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Code Contents Causes
Check procedures/
corrective measures

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
