Kyocera FS-C8600DN Service Manual

2MN/2N1
1-4-23
6100 DF paper entry sensor
non arrival jam
DF paper entry sensor (DFPES) is not turned on even
if a specified time has elapsed after the machine eject
signal was received (4000-sheet finisher).
H
6101 DF paper entry sensor (DFPES) is not turned on even
if a specified time has elapsed after the machine eject
signal was received (1000-sheet finisher).
H
6110 DF paper entry sensor
stay jam
DF paper entry sensor (DFPES) is not turned off within
specified time of its turning on (4000-sheet finisher).
H
6111 DF paper entry sensor (DFPES) is not turned off within
specified time of its turning on (1000-sheet finisher).
H
6200 DF sub eject sensor non
arrival jam
DF sub eject sensor (DFSES) does not turn on within
specified time of DF paper entry sensor (DFPES) turn-
ing on.
H
6210 DF sub eject sensor stay
jam
DF sub eject sensor (DFSES) is not turned off within
specified time of its turning on.
H
6300 DF middle eject sensor
non arrival jam
DF middle eject sensor (DFMES) does not turn on
within specified time of DF paper entry sensor
(DFPES) turning on (4000-sheet finisher).
H
6301 DF middle eject sensor (DFMES) does not turn on
within specified time of DF paper entry sensor
(DFPES) turning on (1000-sheet finisher).
H
6310 DF middle eject sensor
stay jam
DF middle eject sensor (DFMES) is not turned off
within specified time of its turning on (4000-sheet fin-
isher).
H
6311 DF middle eject sensor (DFMES) is not turned off
within specified time of its turning on (1000-sheet fin-
isher)
H
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-1 for paper misfeed indication (see page 1-4-1).
