Kyocera FS-C8600DN Service Manual

2MN/2N1
1-2-16
1. Install the optional devices (job separa-
tor, document finisher and/or fax kit
etc.) as necessary.
1. Install the optional cassette heater as
necessary (see page 1-2-21).
1. Connect the power cord to the power
cord connector on rear lower of the
machine.
2. Connect the power plug to the wall out-
let.
1. Turn the main power switch on.
2. Check the messages on the operation panel
After completion of warming up, in case to display "Warning for high temperature. Adjust the room tem-
perature." on the operation panel, follow the step 3. (Performing Drum Refresh)
In case to display “Warning for low temperature. Adjust the room temperature.” on the operation panel,
install the machine in the other location this message won’t be shown.
Installing the machine in a low temperature environment could cause image quality problems.
In case to have no display, follow the step 4 (Performing LSU cleaning).
*: Perform the high altitude settings when a leakage is developed on images in a high altitude installation,
such as in Mexico City.
U140 - AC Calb - High Altitude - Mode 2
3. Performing drum refresh (see the operation guide)
Press the Menu key.
In the Adjust/Maint. menu screen, press cursor key to select Service Setting.
Press the OK key.
In the Service Setting. menu screen, press cursor key to select [Durm].
Press [OK]. A confirmation screen appears.
Press [Yes] ([Left select key]).
Installing optional devices
Installing the cassette heater (option)
Connect the power cord
Adjusting the image

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
