Kyocera FS-C8600DN Service Manual

2MN/2N1
2-4-1
2-4 Appendixes
2-4-1 Appendixes
(1) List of maintenance parts
Maintenance part name
Part No.
Alternative
part No.
Name used in service manual Name used in parts list
Paper feed pulley
PULLEY FEED 302K906350 2K906350
Separation pulley
PULLEY RETARD 302K906360 2K906360
Forwarding pulley
PULLEY PICKUP 302K906370 2K906370
Lower duplex roller
PARTS ROLLER DU LOW SP 302K994470 2K994470
Middle duplex roller
PARTS ROLLER DU MID SP 302K994480 2K994480
Upper duplex roller
PARTS ROLLER DU UP SP 302K994490 2K994490
Eject roller
PARTS ROLLER EXIT SP 302LC94350 2LC94350
Fan filter
PARTS FILTER FAN ASSY(V) SP 302LC94170 2LC94170
Developer filter
FILTER DLP COOLING 302LC33500 2LC33500
Transfer belt filter
PARTS FILTER BELT UNIT(V) SP 302LC94130 2LC94130
Toner filter
FILTER LEFT SIDE 302LC33370 2LC33370
Left filter
FILTER LEFT SIDE 302LC33370 2LC33370
Eject filter
PARTS FILTER EXIT UNIT SP 302K994100 2K994100

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
