Kyocera FS-C8600DN - Removing the Tapes

2MN/2N1
1-2-6
1. Remove two tapes and the protect
sheet.
2. Remove tape and the top spacer.
Figure 1-2-6
3. Remove tape and then two protect
sheets.
4. Remove three tapes and then protect
sheet.
5. Remove tape and then silica gel.
Figure 1-2-7
Removing the tapes
Protect sheet
Tape
Tape s
Top spacer
Tape
Protect sheets
Silica gel
Tape
