Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-61
U108 Setting separation shift bias
Description
Adjusts output of separation shift bias and ON/OFF timing.
Purpose
To set when the separated malfunction of the paper occurs.
Method
1. Press the OK key.
2. Select the item to be set.
*: 55 ppm model only.
Setting: [Output]
1. Select the item to be set.
2. Change the setting value using the numeric keys or numeric key.
3. Press the OK key. The value is set.
Item No. Description
Display Description
Output Adjusting the separation shift bias output
Output 3/4 Adjusting the separation shift bias output
Output B/W* Adjusting the separation shift bias output in black/white mode
Timing Adjusting the ON/OFF timing with paper position
Subtraction Value
Display Description
Setting
range
Initial
setting
Light 1st Separation shift bias for the first side on
paper with thickness 52 to 64 g/m
2
0 to 255 55
Light 2nd Separation shift bias for the second side
on paper with thickness 52 to 64 g/m
2
0 to 255 55
Normal 1st Separation shift bias for the first side on
paper with thickness 65 to 75 g/m
2
0 to 255 55
Normal 2nd Separation shift bias for the second side
on paper with thickness 65 to 75 g/m
2
0 to 255 55
Add Lead Addition value for leading edge on paper
with thickness 76 to 105 g/m
2
-127 to 127 0
Heavy/OHP Separation shift bias for transparencies
or paper with thickness 106 to 300 g/m
2
0 to 255 0
