Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-96
U246 Setting the finisher
Description
Provides various settings for the 1000-sheet finisher or 4000-sheet finisher, if furnished.
Purpose
1. Adjustment of registration stop timing in punch mode
Adjust if skewed paper conveying occurs or if the print paper is Z-folded in punch mode.
2. Adjustment of paper stop timing in the punch mode
To adjust this item when the position of a punch hole is different from the specified one.
3. Adjustment of center position timing in the punch mode
Adjusts the center position of a punch hole in punch mode if the position is not proper.
4. Adjustment of front/rear side registration home position
Provides optimization when paper jam occurs due to an inferior fitting of the side registration
guides to paper.
5. Adjustment of front/rear shift home position
Performed when adjustment is lost with the ejected paper
6. Adjusting of front/back stapling home position
Adjusts the stapling position in the staple mode if the position is not proper.
7. Adjustment of upper/lower side registration home position
Provides optimization when paper jam occurs due to an inferior fitting of the side registration
guides to paper.
8. Adjustment of booklet stapling position
Adjusts the booklet stapling position in the stitching mode if the position is not proper.
9. Adjustment of center folding position
Adjusts the center folding position in the stitching mode if the position is not proper.
10. Adjustment of tri- folding position
Adjusts the tri-folding position in the stitching mode if the position is not proper.
Method
1. Press the OK key.
2. Select the item to set.
3. Press the OK key.
Method: [Finisher]
1. Select the item to set.
Item No. Description
Display Description
Finisher Adjustment of 1000-sheet finisher and 4000-sheet finisher
Booklet Adjustment of center-folding unit
Display Description
Punch Regist 1.Adjustment of registration stop timing in punch mode
Punch Feed 2.Adjustment of the paper stop timing in punch mode
Punch Width 3.Adjustment of the center position timing in punch mode
WidthFront HP 4.Adjustment of front side registration home position
WidthTail HP 4.Adjustment of rear side registration home position
ShiftFront HP 5.Adjustment of front shift home position
ShiftTail HP 5.Adjustment of rear shift home position
Staple HP 6.Adjustment of front and back stapling home position
