Kyocera FS-C8600DN - PF Paper Conveying Sensor 1 Non Arrival Jam; PF Paper Conveying Sensor 2 Stay Jam

2MN/2N1
1-4-8
2317 PF paper conveying sen-
sor 2 stay jam
PF paper conveying sensor 2 (PFPCS2) does not turn
off during paper feed from cassette 7 (side paper
feeder).
K
2603 PF paper conveying sen-
sor 1 non arrival jam
PF paper conveying sensor 1 (PFPCS1) does not turn
on during paper feed from cassette 3 (large capacity
feeder).
C
2604 PF paper conveying sensor 1 (PFPCS1) does not turn
on during paper feed from cassette 4 (large capacity
feeder).
C
2606 PF paper conveying sensor 1 (PFPCS1) does not turn
on during paper feed from cassette 6 (side large
capacity feeder).
K
2607 PF paper conveying sensor 1 (PFPCS1) does not turn
on during paper feed from cassette 7 (side large
capacity feeder).
K
2613 PF paper conveying sen-
sor 1 stay jam
PF paper conveying sensor 1 (PFPCS1) does not turn
off during paper feed from cassette 3 (large capacity
feeder).
E
2614 PF paper conveying sensor 1 (PFPCS1) does not turn
off during paper feed from cassette 4 (large capacity
feeder).
E
2616 PF paper conveying sensor 1 (PFPCS1) does not turn
off during paper feed from cassette 6 (side large
capacity feeder).
J
2617 PF paper conveying sensor 1 (PFPCS1) does not turn
off during paper feed from cassette 7 (side large
capacity feeder).
J
2704 PF paper conveying sen-
sor 2 non arrival jam
PF paper conveying sensor 2 (PFPCS2) does not turn
on during paper feed from cassette 4 (large capacity
feeder).
C
2707 PF paper conveying sensor 2 (PFPCS2) does not turn
on during paper feed from cassette 7 (side large
capacity feeder).
K
2714 PF paper conveying sen-
sor 2 stay jam
PF paper conveying sensor 2 (PFPCS2) does not turn
off during paper feed from cassette 4 (large capacity
feeder).
E
2717 PF paper conveying sensor 2 (PFPCS2) does not turn
off during paper feed from cassette 7 (side large
capacity feeder).
J
Code Contents Conditions
Jam
location*
*: Refer to figure 1-4-1 for paper misfeed indication (see page 1-4-1).
