Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-116
U460 Adjusting the conveying sensor
Description
Compensates the threshold value of the side multi tray’s multi feed sensor.
Purpose
If more than one sheet is fed at a time, modify the threshold depending on the environment.
Method
1. Press the OK key.
2. Select [SMT].
Method
1. Select the item.
Setting: [Conveying Sensor]
1. Select the item.
Setting: [Threshold(S)/(M)]
1. Select the item.
2. Change the setting value using the numeric keys.
3. Press the OK key. The value is set.
Method: [Execute]
1. Select [Execute].
2. Press the OK key. Calibration is executed.
Item No. Description
Display Description
SMT Settings of multiple feed sensor on the side multi tray
Display Description
Conveying Sensor Multi feed sensor settings/Calibration
On/Off Config Multi feed sensor On/Off settings
Display Description
Threshold(S) Paper feeding threshold settings
Threshold(M) Multi feed threshold settings
Sensor(Non-P) Empty paper sensor display
Sensor Displaying sensor value when paper is present
Execute Executing the calibration
Display Description
Setting
range
Initial
setting
Threshold(S) Paper feeding threshold settings 0 to 254 0
Threshold(M) Multi feed threshold settings 0 to 254 0
