Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-149
U977 Data capture mode
Description
Store the print data sent to the machine into USB memory.
Purpose
In case to occur the error at printing, check the print data sent to the machine.
Method
1. Perform shut-down on the operation panel, turn power off(see page P.1-2-19).
2. Insert USB memory in USB memory slot.
3. Turn the main power switch on.
4. Enter maintenance item U977.
5. Select [Execute].
6. Press the OK key.
7. Send the print data to the machine.
Once the print data is stored into USB memory, [OK] will be displayed.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Error codes
U984 Checking the developer unit number
Description
Displays the developer unit number.
Purpose
To check the developer unit number.
Method
1. Press the OK key. The developer unit number for each color is displayed.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Error codes Description
1 The removable memory has been crushed or removed or
write-protected
2 The removable memory is full
3 Other errors have occurred
Display Description
C Cyan developer unit number
M Magenta developer unit number
Y Yellow developer unit number
K Black developer unit number
